Micro AC Gear Motor
AC micro geared motor can be directly connected to single phase or three phase power supply to operate.
There are induction motors, reversible motors, magnetic brake motors, variable speed motors, torque motors, and other specification.
Geared motor can be matched with gearbox and speed regulation controller.
Motor rated power ranges from 6W to 250W.And are available as a round shaft motor only or with a parallel gearhead or right angle gearhead.
The gear motor compact size, low noise, high reliability, long lifespan and easy installation.
It can be used in continuous operation. And it has been widely used in various applications, such as woodworking industry, textile industry, food industry, packaging industry, and industrial automation machinery, etc.
| (1) Outline Dimension | 2: □ 60mm, 3: □ 70mm, 4: □ 80mm, 5: □ 90mm, 6: □ 104mm |
| (2) Type of models | I: Three-phase induction type R: Single-phase reversible type T: Torque type |
| (3) Motor series | K Series |
| (4) Power | 6W, 15W, 25W, 40W, 60W, 90W, 120W, 140W, 180W, 200W, 250W |
| (5) Motor types | R: Speed control motor |
| (6)Motor shaft shapes | A: Round shaft, GN: Helical gear shaft (gearbox applicable motor frame size 60/70/80/90), GU: Helical gear shaft (gearbox applicable motor frame size 100) |
| (7)Voltage | A: Single-phase 110V C: Single-phase 220V S2: Three-phase 380/220V S3: Three-phase 380V SS3: Three-phase 220V/380V interchangeable S4: Three-phase other voltage |
| (8)Accessories | T: Terminal box, TP: Overheating protection device, Q1: 110V forced air cooling, Q2: 220V forced air cooling, Z: damping, F: Fan, M: Electromagnetic brake (unpowered), M2: Electromagnetic brake (powered), H: Bracket |
